HDPE silicon-core pipe extrusion line

Price: 50000.0~100000.0 USD
Place of Origin: Shandong, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: SJ series
Packing: Packing in film or wood cas...
Plastic Type: PP/PE
Shaft Design: Single
Power: 120kw
HDPE wire protect pipe making machine: HDPE silicon-inside pipe ma...
Production Capacity: 60 sets per year
Delivery Date: Within in 45 working days a...
Use: Others
Brand Name: changjie
Capacity: 310kg/h

HDPE silicon-core pipe production line
1.Pipe diameter:20-63mm
2.Power:120kw
3.Producing speed:6-14m/min

HDPE silicon-core pipe production line
1.Extruder of pipe line: DC speed regulator and high performance BM type screw, spiral co-extrusion die-head.
2.Vacuum calibrator of HDPE pipe line: vacuum negative pressure calibrating and circulating spraying cooling system made of 24 meter stainless steel.
3.Haul- off unit of plastic pipe line: equipped with an automatic clamping system, frequency conversion for speed controlling and stable haul-off.
4.PLC control system of plastic pipe line, realize programmed control of the temperature, extrusion amount,length set, haul-off and automatic printing.
Technical parameter:
Model

Extruser Diameter
90MM
45MM
30MM
L/D ratio
30:1
30:1
25:1
Output
260kg/h
40kg/h
10kg/h
Installed power
120KW
Specifications
20-63mm
Haul-off speed
6-14m/min
Overall dimension(L*W*H)
40*3*2.5m
